NeoDen IN12C Reflow Soldering Machine

Introduction of NeoDen IN12C Reflow Oven

NeoDen IN12C is an environmentally friendly, stable performance intelligent automatic orbital reflow soldering. This reflow solder adopts the exclusive patented design of "even temperature heating plate", with excellent soldering performance. With a 12-temperature zone compact design, it is lightweight and compact. The device achieves intelligent temperature control with a high-sensitivity temperature sensor, ensuring stable temperature inside the furnace and minimal horizontal temperature difference. It also uses Japan NSK hot air motor bearings and Swiss-imported heating wires for durable and stable performance. The IN12C has passed CE certification to provide authoritative quality assurance.

Why Choose NeoDen IN12C?

【Excellent Soldering Performance】 The IN12C uses hot air convection and a high-performance aluminum alloy heating plate instead of heating tubes, which significantly reduces the lateral temperature deviation compared to similar reflow ovens on the market.

【Intelligent Control & Easy to Use】 The control system has the characteristics of high integration, timely response, low failure rate, and easy maintenance. It is an intelligent, custom-developed control system integrated with the PID control algorithm, which is easy to use and powerful. It can store 40 working files.

【Precise and Efficient Temperature】 The temperature control accuracy is up to ±0.5%. The unique heating module design features high-precision temperature control, uniform temperature distribution in the thermal compensation area, high efficiency of thermal compensation, and low power consumption.

【Eco-friendly and Energy-saving】 It has a built-in welding fume filtration system, effectively filtering harmful gases, making it beautiful and environmentally friendly. All temperature zones and the cold air zone have adjustable wind speed, making it easy to cope with a variety of welding needs. With low power consumption and low power supply requirements, ordinary civilian electricity can meet its use. Compared to similar products, the electricity costs saved in a year can be enough to buy another unit of this product.

【Durable and Safe】 The internal temperature box is made of stainless steel, which is environmentally friendly and odorless , and is equipped with heat insulation cotton to effectively prevent heat loss. The top cover has an automatic limit after being opened, effectively ensuring production safety.

【Precise Welding Capability】 The custom-developed stainless steel B-type mesh belt is durable and wear-resistant. The high-precision profile process completes the mesh chain wheel, with a unique support structure that can effectively reduce the vibration of the PCB board in the reflow area, making it easy to handle welding of small 0201 class devices and BGA class complex chips.

【Real-time Monitoring】 A unique 4-way board surface temperature monitoring system provides timely and comprehensive feedback data.

Specification

Features of NeoDen IN12C

12 Heating Zones

Uniform temperature

High temperature control accuracy

Energy saving & Eco-friendly

Welding smoke filtering system

low power and supply requirements

Cooling Zone

Independent circulating air design

Isolates the influence of the external environment

Operation Panel

Hidden screen design

Convenient for transportation

Intelligent Control System

Custom developed intelligent control system

Temperature curve can be displayed

Elegant Appearance

In line with high-end use environment

Lightweight, miniaturization, professional



Packaging & Shipping

Packaging

• One piece in one wooden case
• Suitable quantity to an export wooden case
• Other packing accessories in regular
• Customer required packing is available

Shipping

by air, sea, or express

Delivery time

about 15~30 days after order details and production confirmed.



NeoDen IN12C Customer cases

Case Study: IN12C 12-Zone Reflow Oven in University Advanced SMT Teaching Lab

✓ High-End Academic Lab

Client Location: Indonesia 🇮🇩

🎓 Higher Education & Advanced Engineering Research

Full Smart SMT Line Configuration:
PCB Loader + ND2 Printer + S1 SPI + K1830 Pick & Place + IN12C Reflow Oven + ND800 AOI + PCB Unloader

This leading Indonesian university established an industry-grade SMT demonstration center for engineering education and advanced Electronics R&D. Featuring the NeoDen IN12C reflow oven coupled with S1 SPI and ND800 AOI inspection, this high-precision line provides students and researchers with complete, zero-defect automated manufacturing capabilities.

Complete IN12C Smart SMT Line operating at University Lab in Indonesia

Read Full Case Study

Case Study: High-Speed Dual-Pick-and-Place SMT Line with IN12C in France

✓ Industrial Automation Line

High-speed dual-head inline SMT setup operating in France

Read Full Case Study

Client Location: France 🇫🇷

💻 Electronics & Computer Hardware R&D / Manufacturing

Full Industrial Dual-Line Setup:
PCB Loader + ND2 Automatic Printer + S1 SPI + N10P + N10P + ND800 AOI + Buffer Conveyor + IN12C 12-Zone Reflow Oven + PCB Unloader

This French electronics and computing technology manufacturer integrated the NeoDen IN12C 12-zone reflow oven into a high-capacity, dual-N10P pick-and-place production line. Combined with inline 3D SPI, AOI inspection, and smart buffer system, the IN12C delivers superior thermal equilibrium required for continuous, high-volume production of complex computing hardware.

If you need, please feel free to contact us for more information.



About NeoDen



Factory





Quick facts about NeoDen

1) Established in 2010, 200 + employees, 27000+ Sq.m. factory.

2) NeoDen Products:Different Series PnP machines, NeoDen YY1, NeoDen4, NeoDen5, NeoDen K1830, NeoDen9, NeoDen N10P. Reflow Oven IN Series, as well as complete SMT Line includes all necessary SMT equipment.

3) Successful 10000+ customers across the globe.

4) 40+ Global Agents covered in Asia, Europe, America, Oceania and Africa.

5) R&D Center: 3 R&D departments with 25+ professional R&D engineers.

6) Listed with CE and got 70+ patents.

7) 30+ quality control and technical support engineers, 15+ senior international sales, for timely customer responding within 8 hours, and professional solutions providing within 24 hours.



Exhibition







Certification





If you need, please feel free to contact us for more information.



FAQ

Q: How many heating zones does the NeoDen IN12C have?

IN12C: has 12 heating zones, upper 6 and down 6.

Q: Can this machine connect directly to the unloader?

IN12C with track transmission, can connect directly to the unloader.

Q: Does the NeoDen reflow oven support double-sided PCBs?

IN6C, IN8C, IN12C with track transmission supports double-sided PCBs.
IN6 with mesh chain, not suitable for double-sided PCB.

Q: What Is the Warranty Policy for the NeoDen reflow oven?

Warranty period: 2 years from delivery date.

Free replacement of necessary spare parts during warranty.

Lifetime technical support provided free of charge.
