Pick and Place Machine

A: We classify our placement equipment into three production tiers based on actual throughput (CPH - Components Per Hour) and factory footprint:

Prototyping & Small-Batch Labs:

• NeoDen YY1: Features a single gantry with 2 heads, offering a vision-on speed of 3,000 CPH. It handles a 315x350mm max PCB size and is perfect for startups or R&D labs seeking a low-budget, highly stable solution.
• NeoDen4: A desktop companion with 4 placement heads, reaching 4,000 CPH (with vision) and up to 10,000 CPH (without vision). It is ideal for small businesses stepping up from manual assembly to automation.

Medium-Scale Flexible SMT Production:

• NeoDen9: Featuring 6 independent heads and a Panasonic 400W servo system. It delivers a reliable average mounting speed of 9,000 CPH (Max 14,000 CPH), making it excellent for flexible job shops.

High-Volume & Long-LED Assembly Lines:

• NeoDen N10P: Engineered for high efficiency with 8 synchronized heads and a massive 20,000 CPH max speed. It natively supports high-density batch production.

• NeoDen YY1: Features an integrated 3-slot automatic nozzle changer on a patent-protected linear rail module, minimizing manual intervention for entry-level tasks.
• NeoDen N10P: Implements an advanced 39-position automatic nozzle changer with auto-height calibration. This drastically boosts throughput for complex boards requiring distinct vacuum nozzle profiles.

A: Feeder real estate determines how many unique line items you can load concurrently without changeovers. Board handling dimensions define your product limits:

NeoDen YY1 Feeder capacity:

• 52 Tape Feeder (all 8mm)
• 4 Stick Feeder
• 28 Flexible Feeder
• 19 Bulk Feeders

Accommodates a max single-side tape PCB width of 315 * 350mm.

NeoDen4 Feeder capacity:

48 tape reel feeders

5 vibrating feeders

Features an online dual-rail system that handles overlong boards up to 310 * 1500mm via integrated conveyor processing.

NeoDen9:

• Fits 53 slots for Yamaha Electric/Pneumatic feeders.
• Supports a max PCB size of 460 * 300mm.

NeoDen N10P Feeder capacity:

• 80 Tape & Reel feeder (33 front + 47 rear)
• 1 IC Tray

Allowing mixed usage of electric and pneumatic units on the same base. It natively handles heavy oversized panels up to 450x1500mm via extension conveyor.

A: NeoDen leverages specialized hardware layers across models to secure consistent tracking and verification:

• Flying Vision & Optical Arrays: NeoDen9 utilizes a 5-megapixel industrial HD lens powered by a 289-LED ring shadowless light source to align parts mid-flight. NeoDen N10P scales this with dual 4th-generation flying camera arrays using premium US ON Semiconductor sensors and 28mm industrial optics.
• True Closed-Loop Control: NeoDen9 and NeoDen N10P drop stepper mechanics in favor of Panasonic A6 Servo Motors paired with advanced Magnetic Linear Encoders/Scales. This achieves true closed-loop feedback, guaranteeing that accuracy does not degrade over long production cycles.
• Pneumatic & Vacuum Fail-safes: The NeoDen N10P features real-time nozzle air pressure monitoring. If an abnormal vacuum profile occurs, the placement sequence triggers an automated pause to completely eliminate material waste and head collisions.

• Certifications: NeoDen SMT machines have approved CE compliance certified by TUV NORD, meeting rigorous European health, safety, and environmental directives.
• Global Local Support: Backed by 40+ global partners spanning Europe, the Americas, Asia, Oceania, and Africa, NeoDen services 10,000+ active end-users globally.
• Support SLA: English-fluent support engineers guarantee an initial response within 8 hours and comprehensive technical solutions within 24 hours. Every pick and place machine ships with life-long technical support and regular, complimentary software system updates.
