NeoDen ND 56X X-Ray Inspection Machine
Introduction of NeoDen ND56X X-ray Inspection Machine
The NeoDen ND56X is a small, precise microfocus X-ray inspection equipment, ideal for R&D, labs, and quality control. It is compact and easy to use, providing high-resolution images quickly. It features automated functions like infrared navigation and CNC multi-point inspection, along with multi-angle tilt and 360° rotation for comprehensive defect analysis. The device is highly safe with ultra-low radiation leakage and complies with CE and SEMI S2/S8 safety standards.
Features
【Small and Precise, Easy to Operate】 The NeoDen ND56X is a small, microfocus X-ray inspection equipment , which is easy to install and operate.
【High Resolution, Fast Imaging】 It features a high resolution design to get the best image in a very short time.
【Multiple Automated Functions】 It has an infrared automatic navigation and positioning function , supports CNC automatic multi-point inspection, can automatically calculate void ratio, and can automatically detect defects such as size, broken wires, and bridging.
【Enhanced BGA Inspection】 It can manually or automatically identify BGA solder balls and complete the inspection.
【Multi-Angle Inspection with No Blind Spots】 The loading platform supports a tilt angle of ±30° , and is equipped with a rotating manipulator that can rotate 360° to take images.
【Comprehensive Measurement Tools】 It provides various measuring tools, such as distance, angle, circle radius, circumference, and more.
【Highly Safe】 The design standard for radiation leakage is ≤0.5uSv/h , which is lower than the exemption standard of ≤1uSv/h. It has obtained an exemption record from the Ministry of Ecology and Environment of the People's Republic of China , and is equipped with a triple safety protection sensor.
Specification of ND56X
| Product name | NeoDen ND 56X X-Ray Inspection Machine | Micro Focus Spot Size | 15μm |
| Model | ND 56X | Max Sample Size | 280mm×320mm |
| Voltage Range | 40-90KV | Input Power | 220V 10A/110V 15A 50-60HZ |
| Current Range | 10-200 μA | Dimensions | L850mm×W1000mm×H1700mm |
| Max Output Power | 8 W | Net Weight About | 750KG |
Details
Our Service
Provide product instructions.
YouTube video tutorials.
Experienced after-sales technicians, 24 hours online service.
With our own manufactory and more than 10 years of experience in SMT industry.
We can provide customers with the most cost-effective products.
video
Provide one-stop SMT assembly production line
About NeoDen SMT
factory
Zhejiang NeoDen Technology Co., Ltd. has been manufacturing and exporting various small pick and place machines since 2010. Taking advantage of our own rich experienced R&D, well trained production, NeoDen wins great reputation from the world wide customers.
① Established in 2010, 200+ employees, 8000+ Sq.m. factory
② NeoDen products: Smart series PNP machine, NeoDen K1830, NeoDen4, NeoDen3V, NeoDen7, NeoDen6, TM220A, TM240A, TM245P, reflow oven IN6, IN12, Solder paste printer FP2636, PM3040
certification
exhibition
If you need, please feel free to contact uf for more information.
FAQ
Q1. What Is the Imaging Resolution of the ND56X X-Ray Machine?
The imaging resolution is 1536 × 1536 pixels.
Q2. What is ND56X X-ray machine?
The offline ND56X is an industrial inspection machine, suitable for 3C, SMT, EMS, semiconductor casting industries, etc.
Q3. Is the NeoDen ND56X Easy to Operate and Maintain?
Yes:
It is an offline device , making it easy to operate.
The X-ray tube and FPD require no maintenance during normal use.
Operators can learn to use the system within approximately one hour.
Q4. What Components Can the ND56X Inspect?
The machine supports inspection of:
- Chips
- BGA / CSP packages
- Wafers
- SOP / QFN packages
- SMT components
- PTU modules
