Table top full hot air convection reflow oven

Feature

1. Five heating zones can make inside temperature more accurate and well-proportioned, just need 15-20mins to reach the working temperature.

(First: Fast preheat zone Second:Soldering zone; Third: Drying zone Fourth/Fifth: Bottom-side heat zones)

2. Using AC motor to drive the conveyor belt, chain type transmission way. Speed adjustment is controlled by automatic electronic analog switch, which sensitivity no more than 1 degree, control accuracy ±10mm/min.

3. Support working under both single Phase (220V) and Three phases (380V), suit both lead or lead-free solder paste.

4. Cooling fan: Mainly to cool the welded PCB, or cool the heat parts inside machine to guarantee their good work.

5. Signal lights: Supervise the work condition of the machine, that is,signal lights indicate the temperature of the machine in normal and abnormal working state.

6. Emergency Stop Button-Support Abnormal Shutdown during breakdown situation.

7.Support adjust the height of the base, which is convenient to build a Complete Automatic SMT Production Line with other SMT Machines.

Specification

Product name	Table top full hot air convection reflow oven	Working Power	3KW
Model	NeoDen T5	Input Voltage	380/220V
*LengthWidthHeight*	1700612650mm	Conveyor Width	300mm
N.W	120KG	Standard Height	20mm
Peak Power	7KW	Max Customized Height	55mm
Max Speed of Conveyor	1200mm

Our Service

1. Provide video tutorial after purchasing the product.

2. 24-hour online support.

3. Professional after-sales technical team.

4. Free broken parts (Within 1 Year warranty).

Provide one-stop SMT assembly production line

N4+IN6

FAQ

Q1: How can I buy machine from you?

A: (1) Consult us on line or by e-mail.

(2) Negotiate and confirm the final price, shipping, payment method and other terms.

(3) Send you the perfroma invoice and confirm your order.

(4) Make the payment according to the method put on proforma nvoice.

(5) We prepare your order in terms of the proforma invoice after confirming your full payment. And 100% quality check before shipping.

(6) Send your order via express or by air or by sea.

Q2: This is the first time I use this kind of machine, is it easy to operate?

A: Yes. There are English manual and guide video that show you how to use machine.

If there is any doubt in the process of operating the machine, please feel free contact us.

We also provide overseas on-site service.

Q3: Are you a trade company or a manufacturer?

A: We are an professional manufacturer specialized in SMT Machine, Pick and Place Machine, Reflow Oven, Screen Printer, SMT Production Line and other SMT Products.

About Us

Factory
