NeoDen ND200 Wave Soldering Machine
Wave Q'ty: Double Wave
Conveyor Speed: 0-1.2m/min
Wave Height: 12mm
Send Inquiry
Product Details ofNeoDen ND200 Wave Soldering Machine
Feature
Heating Method: Hot Wind
Cooling method: Axial fan
Transfer Direction: Left→Right
Temperature Control: PID+SSR
Machine Control: Mitsubishi PLC+ Touch Screen
Flux tank capacity: Max 5.2L
Spray Method: Step Motor+ST-6
Specification
| Product Name | Wave Soldering Machine | Preheating Zones | Room temperature-180℃ |
| Wave | Double Wave | Solder temperature | Room Temperature-300℃ |
| Tin tank capacity | 180-200KG | Machine size | 1400*1200*1500mm |
| Preheating | 450mm | Packing size | 2200*1200*1600mm |
| Wave Height | 12mm | Transfer speed | 0-1.2m/min |
| PCB Conveyor Height | 750±20mm | Air source | 4-7KG/CM2 12.5L/Min |
Quality control
We have QC person stay on the production lines do to the inspection.
All products must have been inspected before delivery.
we do inline inspection and final inspection.
1. All raw material checked once it arrive our factory.
2. All pieces and logo and all details checked during production.
3. All packing details checked during production.
4. All production quality and packing checked on final inspection after finished.
If you need, please feel free to contact us for more information.
Provide one-stop SMT assembly production line
FAQ
Q1: What products you sell?
A: Our company deal in the following products:
SMT equipment.
SMT accessories: Feeders, Feeder parts.
SMT nozzles, nozzle cleaning machine, nozzle filter.
Q2: What's the way of shipping?
A: These are all heavy machines;
we suggest you use cargo ship.
But components for mending the machines, air transportation would be fine.
Q3: Can we customize the machine?
A: Of course. All of our machines can be customized.
About us
factory
exhibition
certification
If you need, please feel free to contact us for more information.
