Pick and Place Robot Machine
NeoDen 3V has been discontinued. Looking for an upgrade?
Discover the NeoDen YY1, a more powerful and cost-effective alternative built to exceed your needs.
Pick and place robot machine NeoDen 3V video
Specification
|
Produt name |
Pick and place robot machine NeoDen 3V (Advanced) |
|
Number of heads |
2 |
|
Alignment |
Vision |
|
Rotation |
±180° |
|
Placement Rate |
5000CPH (without vision); 3500CPH (with vision) |
|
Feeder Capacity |
Tape feeder: 44 (all 8mm) |
|
Vibration feeder: 0~5 |
|
|
Tray feeder: 5~10 (Customization supported) |
|
|
Board Dimension |
Maximum: 320*390mm |
|
Component Range |
Smallest components: 0402 |
|
Largest components: TQFP144 |
|
|
Max height: 5mm |
|
|
Numbers Of Pumps |
3 |
|
Placement Accuracy |
±0.02mm |
|
Operate System |
Windows XP-NOVA |
|
Power |
160~200W |
|
Electricity Supply |
110V/220V |
|
Machine Size |
820(L)*680(W)*410(H)mm |
|
Packing Size |
1001(L)*790(W)*568(H)mm |
| N.W./G.W. |
60Kg/85Kg |
Details
Full vision 2 heads system
2 high-precision placement heads with ±180°
rotation could satisfy the need of wide range components.
Flexible PCB positioning
By using PCB support bars and pins, wherever you want
to put the PCB and whatever the shape of your PCB is, all can be handled well.
Patented Automatic Peel-box
Patented electromagnetic actuators, you don't need to get rid of
the wasted nylon film manually, which saves you more time and effort.
Integrated Controller
More stable performance and easier to do maintenance.
PCB Angle Correction
PCB angle will influence the accuracy of mounting.
The angle more closer to 0 degree the better, and the angel deviation need to be within 1 degree.
The angle of PCB is generated according to panelized PCB coordinates, but we can also adjust the angle by manual.
Click" PCB angle" button, according to the index of machine to choose two points, then a new PCB angle will be generated. (Note, the two points need to be in one vertical or horizontal line)
Under panelized PCB mode, " PCB angle" is locked. You need to correct from panelized PCB to single PCB( 1*1), after confirm the PCB angle, you can change back to panelized PCB model.
Quality control
We have QC person stay on the production lines do to the inspection.
All products must have been inspected before delivery.
We do inline inspection and final inspection.
1. All raw material checked once it arrive our factory.
2. All pieces and logo and all details checked during production.
3. All packing details checked during production.
4. All production quality and packing checked on final inspection after finished.
Provide one-stop SMT assembly production line
Related product
 |
 |
 |
| Stencil printer FP2636 | SMT pick and place machine NeoDen4 | Pick and place machine NeoDen K1830 |
Especially a good choice for customers who prefer in prototype project as a startup device. If you need, please feel free to coantact us.
FAQ
Q1: What we can do for you?
A: Total SMT Machines and Solution, professional Technical Support and Service.
Q2: What products you sell?
A: Our company deal in the following products:
SMT equipment
SMT accessories: Feeders, Feeder parts
SMT nozzles, nozzle cleaning machine, nozzle filter
Q3: What's the way of shipping?
A: These are all heavy machines; we suggest you use cargo ship.
But components for mending the machines, air transportation would be fine.
