NeoDen ND880 Offline AOI Machine
■ 400mm * 360 mm Max PCB Size
■ 50 mm * 50 mm Min PCB Size
■ 800 mm/s Transfer Speed (Max)
NeoDen ND880 offline AOI nachine automatic programming, manual programming, CAD data import, and automatic corresponding to component library. Optimized detection technology covering the whole circuit board. Jointed board and multiple marks, with Bad Mark function.
Send Inquiry
Product Details ofNeoDen ND880 Offline AOI Machine
Description
Image recognition: Automatically set the parameters (e.g. shift, polarity, short circuit, etc.) according to different inspection requirements.
SPC statistical function: Record the test data in the whole process and carry out statistics and analysis, and production status and quality analysis can be viewed in any area.
PCB transmission system: Bottom-up fixing, automatic compensation of PCB deformation, automatic getting in and out of board, and automatic adjustment of width.
Specification
| Product name | NeoDen Offline AOI Machine | Positioning accuracy | ≤16μm |
| Model | ND880 | Moving speed | Max.800mm/sec |
| PCB dimension | 50*50mm(Min) - 400*360mm (Max) | Power Supply | AC220V 50HZ 1800W |
| Image processing speed | 0402 chip < 12ms | Dimensions | L1000*W950*H1580mm |
| Minimum part test | 0402chip & 0.4 pitch IC | Weight | 560KG |
Detection type
Component defects such as whether there is solder paste, offset, insufficient solder, excess solder, open circuit and contamination;
mounting defects such as missing part, offset, skewing, tombstone, mounting on side, turnover, wrong parts, damage and reversal, etc.;
solder joint defects such as excess solder, insufficient solder, pseudo soldering, and solder bridge, etc.;
and PCB defects such as copper foil contaminated, black pad, de-lamination, copper foil missing, and oxidation, etc.
Our Service
1. Good knowledge on different market can meet special requirements.
2. Real manufacturer with our own factory located in Huzhou, China.
3. Strong professional technical team ensure to produce the top quality products.
4. Special cost control system ensure to provide the most favorable price.
5. Rich experience on SMT area.
Provide one-stop SMT assembly production line
About Us
factory
certification
exhibition
Zhejiang NeoDen Technology Co., Ltd. has been manufacturing and exporting various small pick and place machines since 2010. Taking advantage of our own rich experienced R&D, well trained production, NeoDen wins great reputation from the world wide customers.
With global presence in over 130 countries, the excellent performance, high accuracy and reliability of NeoDen PNP machines make them perfect for R&D, professional prototyping and small to medium batch production. We provide professional solution of one stop SMT equipment.
If you need, please feel free to contact uf for more information.
FAQ
Q1. May I know the image processing speed for this model?
A. Image processing speed: 0402chip < 12ms.
Q2. If any difficult question we cannot solve, do you support remote control?
A. Yes, our technical support will share the guidance and start a remote control to check machine's software problem.
Q3. If PCB bottom side with components, what the Max. height limit for ND880?
A. PCB component height: ToP< 30mm, Bottom< 50mm.
