Stencil Printing Machine
Description
This stencil printing machine supports frameless SMT stencils.
The mechanical quick-release frame will save you costs for framing. It supports both single-sided and double-sided PCBs. A squeegee and toolbox included. Accurate X, Y and rotation alignment of the PCB table.
Specification
Product name | Stencil printing machine FP2636 (support frameless stencil) | PCB Thickness | 0- 0.8" - 0-20mm |
Max PCB Size | 11"× 15" - 280×380mm | Platform Height | 7.5" - 190mm |
Min PCB Size | 0.4"× 0.2" - 10×5mm | Repeatability | ±0.01mm |
Screen Stencil Size | 10"× 14" - 260×360mm | Max Rotation Angle | ±15° |
Printing Speed | Labor control | Positioning Mode | Outside/Reference Hole |
Fine Adjustment Range | Z-axis ±15mm X-axis ±15mm Y-axis ±15mm | Net Weight | 12KG |
Positioning Pin Size | ⌀1mm/⌀1.5mm/⌀2.0mm/⌀2.5mm/⌀3mm | Gross Weight | 14KG |
Dimensions | 660×470×245mm |
Details
 |  |
 |  |
Our Service
1. Provide video tutorial after purchasing the product.
2. 24-hour online support.
3. Professional after-sales technical team.
4. Free broken parts (Within 1 Year warranty).
Packing: Carton
Delivery: DHL/FEDEX/UPS/EMS/by sea/by air or customer appointed.
Payment: 100% T/T before shipment.
Lead time: 1-3 business days
About Us
Zhejiang NeoDen Technology is a professional supplier with 10 years experience and provides one-stop SMT solutions for customers, key products are pick&place machine, reflow oven and solder printer. Currently, we have sold 10000+ sets of machines and exported to 130+ countries in the world, and have built a good reputation in the market.
