STD SMD Pick and Place Robot Small Low Volume SMT Machine
SMD pick and place robot small low volum SMT machine
Spotlights
Newly designed software system & UI for visual programming and placement, which allows fast programming on the machine, friendly interface & easy operation.
Linear rail design for X, Y axis to ensure accuracy and stability,and reduce noise at the same time.
Small size with powerful magazines and newly designed tape feeders to support large tape reels configuration flexibly, easy to install and replace tape reels conveniently, to ensure the most excellence solution among all of the entry level machines with lower budget but higher stability.
Equipped with a vacuum detection function, can set standard vacuum detection values on placement head flexibly, all information can be displayed visually on the placement head.
SMT Machine NeoDen YY1 Specification
| Product name | NeoDen YY1 pick and place machine | Nozzle Change Capacity | 3 Nozzles |
| Machine Style |
Single Gantry With 2 Heads |
Component Range | Smallest Size: 0201 |
|
Placement Rate |
Vision On: 3000CPH |
Largest Size: 18*18mm | |
| Vision Off: 4000CPH | Max Height: 12mm | ||
|
Feeder Capacity |
Tape Feeder: 52 (all 8mm) |
Rotation | ±180° |
|
Stick Feeder: 4 |
External Dimensions | Machine Size: 643(L)x530(W)x601(H)mm | |
|
Flexible Feeder: 28 |
Packing Size: 700(L)x580(W)x585(H) mm (wooden box) | ||
|
Bulk Feeder: 19 |
NeoDen is a reliable manufacturer with 14 years' experience.
Until now, we have exported to more than 130 countries and 10000+ sets of machines all over the world, and have built a good reputation in the market.
We are in a good position not only supply you high-quality machines, but also excellent after-sale service.
The well-trained engineer will provide any technical support to you.
Compared with large batch SMT machine, we have the advantage of low budget, high accuracy with small volume, which could help you save much cost for component research and prototype.
Now we have already cooperated with 8 agencies such as India, Japan, Netherlands, South Korea, Iran, Turkey, Brazil, and Chile, the quality has been well accepted by oversea customers, so no need to worry about it.
About Us
factory
certification
exhibition
If you need, please feel free to contact us for more information.
