NeoDen K1830 Pick and place SMD video
NeoDen K1830 Pick and place SMD
Specification
| Product name | NeoDen K1830 Pick and place SMD |
| Nozzle Q'ty | 8pcs |
|
Reel Tape Feeder Q'ty (Max |
66 (Electric / Pneumatic) |
|
Max PCB size |
540*300mm(In Single Step) |
| Placement accuracy | 0.01mm |
|
Max Placement Speed |
16,000CPH |
|
Voltage |
220V/50HZ & 110V/60HZ |
| PCB Transfer Direction | Left→Right |
|
Net Weight |
280Kgs |
| Gross Weight | 360Kgs |
Detail
8 high speed nozzles
1- 8 Synchronized Nozzles which ensure a repeatable placement accuracy with high speed.
2- Machine runs on highly stable and secure Linux operating system.
Vision system
1- Double mark cameras to reach at extreme end feeders for better calibration.
2- High resolution and high speed component camera system improves the overall speed of the machine.
Feeders
1- Closed loop Servo control system with feedback makes the machine to function more accurate.
2- Picking location of pneumatic feeder can be calibrated automatically and promptly, to ensure easy operation and high efficiency.
Suggestions on production process
1. First component confirmation: confirm the component angle and polarity, component picking position and mounting position;
2. Start production after confirming solder paste printing and temperature setting.
If you need, please feel free to contact us for more information.
Provide one-stop SMT assembly production line
FAQ
Q1: Do you provide software updates?
A: Customers who buy our machine, we can offer free upgrades software for you.
Q2: What products you sell?
A: Our company deal in the following products:
SMT equipment
SMT accessories: Feeders, Feeder parts
SMT nozzles, nozzle cleaning machine, nozzle filter
Q3: What's the way of shipping?
A: These are all heavy machines.
We suggest you use cargo ship.
But components for mending the machines, air transportation would be fine.
About us
exhibition
certification
factory
If you need, please don't be hesitate to send your inquiry.
