SMD Component Machine
SMD Component Machine
Products Description
1. Equips with patented sensor technology, it can handle black PCB, and 800mm length PCB can be mounted in sections.
2. The self-developed flying camera recognition system uses imported CMOS sensor, 5 million-level industrial high- definition lens and 289 LED s ring shadowless light sources, to ensure the stable and durable effects.
3. The front and rear feeder stacks are equipped with patent sensors, if the feeder is not installed in the correct position, the placement head will be locked, to avoid head bumps and abnormalities by misoperation.
4. Using the real-time calculation algorithm without virtual parameters for speed counting.
5. Supports both electric feeder and pneumatic feeder at max 53 slots tape reel feeders with machine width 800mm only, to ensure the high efficiency with flexible & worthiest space.
Specification
| Product Name | NeoDen9 SMD Component Machine | Repeat Position Accuracy | ±0.01mm |
| Number of Heads | 6 | Maximum Mounting Speed | 14,000CPH |
| Number of Tape reel Feeders | 53 (Yamaha Electric/Pneumatic) | Average Mounting Speed | 9,000CPH |
| Number of IC Tray | 20 | X-axis-Drive Type | WON Linear Guide / TBI Grinding screw C5 - 1632 |
| Placement Area | 460mm*300mm | Y-axis-Drive Type | WON Linear Guide / TBI Grinding screw C5 - 1632 |
| MAX Mounting Height | 16mm | Compressed Air | ＞0.6Mpa |
| PCB Fiducial Recognition | High Precision Mark Camera | Input Power | 220V/50HZ (110V/60HZ Alternative) |
| Component Recognition | High Resolution Flying Vision Camera System | Machine Weight | 500KG |
| XY Motion feedback control | Closed loop control system | Machine Dimension | L1220mm*W800mm*H1350mm |
| XY Drive motor | Panasonic A6 400W |
Detail
6 Placement Heads
Tape Reel Feeders
Self-developed Flying Camera
C5 precision ground screw
Servo Motor
Patent Sensors
Our Service
Provide product instructions
YouTube video tutorials
Experienced after-sales technicians, 24 hours online service
With our own manufactory and more than 10 years of experience in SMT industry
We can provide customers with the most cost-effective products
If you need, please feel free to contact us for more information.
FAQ
Q1. Is there the products tested before shipping?
A. Yes, of course.
All of our conveyor belt we all will has been 100% QC before shipping.
We test every batch every day.
Q2. How your quality guarantee?
A. We have 100% quality guarantee to customers.
We will be responsible for any quality problem.
Q3. Can we visit your factory before place the order?
A. Yes, very welcome that must be nice to set up good relationship for business.
Q4. Have your products been exported?
A. Yes, they have been exported to USA, Canada, Australia, Russia, Chile, Panama, Nicaragua, UAE, Saudi Arabia, Egypt, Sri Lanka, Nigeria, Iran, Vietnam, Indonisia, Singapore, Greece, Netherland, Georgia, Romania, Ireland, India, Thailand, Pakistan, Philippines, Singapore, HK, Taiwan...
Q5. How far is your factory from the airport and train station?
A. From airport about 2 hours by car, and from train station about 30 minutes.
We can pick up you.
Our Factory
Owned the own machining center, skilled assembler, tester and QC engineers, to ensure the strong abilities for NeoDen machines manufacturing, quality and delivery.
40+ global partners covered in Asia, Europe, America, Oceania and Africa, to successfully serve 10000+ users in all of the world, to ensure the better and faster local service and prompt response.
3 different R&D teams with total 25+ professional R&D engineers, to ensure the better and more advanced developments and new innovation.
Certification
Exhibition
Other Production Line for Your Choice
If you need, please don't be hesitate to send your inquiry.
