Small Desktop Pick And Place Machine

NeoDen4 small desktop pick and place machine Video

Description

Feature

The downward-looking camera: On the head is used for precision location of feeders and PCB placement points. The downwardlooking camera also verifies proper board placement (and compensates for minor board-position  inaccuracies) by auto-aligning the nozzles to multiple fiducials on the board before beginning actual  pick-and-place operations. Once the coordinates are established, the semi-closed-loop stepper motors  are able to repeat these locations to 20µm accuracy without further need for this camera.

The upward-looking camera: located on the right side of the machine. When enabled, this camera first ensures that a component is  attached to the proper nozzle. If the camera detects the absence of a component, the machine will  make up to two additional attempts to pick a component before asking the user for further  instructions. Once a component has been verified as "picked", the camera verifies its position relative  to the nozzle. Because SMDs are small and light, and are held only loosely in their packaging, there  can be a great deal of variation in the actual position of the component when it arrives in "pick"  position and is lifted by the nozzle. The vision system computes the difference between the ideal and  actual position (both X-Y and rotational), and then corrects for any error before precisely placing the  component. Because the vision system continually corrects for even small errors in component  7position on the nozzle, very fine-pitch components (down to 0201) can be placed with repeatable accuracy once the correct coordinates are identified. With these basic understandings, the following  images reveal the basic components of the Neoden4.

Our Service

We are in a good position not only to supply you high quality pnp machine, but also the excellent after sales service.

Well-trained engineers will offer you any technical support.

10 engineers powerful after-sales service team can respond customers queries and enquiries within 8 hours, professional solutions can be offered within 24 hours both workday and holidays.

About Us

NeoDen Tech founded in 2010, is a professional manufacturer specialized in SMT pick and place machine, reflow oven, stencil printing machine, SMT production line and other SMT Products. We have our own R & D team and own factory, taking advantage of our own rich experienced R&D, well trained production, won great reputation from the world wide customers.

You may need, please contact us for more information:

Zhejiang NeoDen Technology Co., Ltd

Web: www.neodensmt.com

Email: info@neodentech.com

FAQ

Q1: Do you provide software updates?

A: Customers who buy our machine, we can offer free upgrades software for you.

Q2: How about the warranty ?

A: We have 2 years warranty for NeoDen4, life time after-sales support.

Q3: Are you a trade company or a manufacturer?

A: We are an professional manufacturer specialized in SMT Machine, Pick and Place Machine, Reflow Oven, Screen Printer, SMT Production Line and other SMT Products.
