Pick and Place Machine BGA
NeoDen 3V Pick and Place Machine BGA Video
NeoDen 3V Pick and Place Machine BGA
Feature
NeoDen 3V are desktop automatic pick and place machines especially developed for research laboratories and small medium manufacturing enterprises however it will also be suitable for the serious hobbyist. These automatic pick and place machines are suitable for small batch production, laboratory research and development, product sample trials, LED SMT processing and other similar processes.
Specification
|
Produt name |
NeoDen 3V pick and place machine BGA |
|
Number of heads |
2 |
|
Alignment |
Vision |
|
Rotation |
±180° |
|
Placement Rate |
5000CPH (without vision); 3500CPH (with vision) |
|
Feeder Capacity |
Tape feeder: 24 (all 8mm) |
|
Vibration feeder: 0~5 |
|
|
Tray feeder: 5~10 (Customization supported) |
|
|
Board Dimension |
Maximum: 320*420mm |
|
Component Range |
Smallest components: 0402 |
|
Largest components: TQFP144 |
|
|
Max height: 5mm |
|
|
Numbers Of Pumps |
3 |
|
Placement Accuracy |
±0.02mm |
|
Operate System |
Windows XP-NOVA |
|
Power |
160~200W |
|
Electricity Supply |
110V/220V |
|
Machine Size |
820(L)*650(W)*410(H)mm |
|
Packing Size |
1001(L)*961(W)*568(H)mm |
| N.W./G.W. |
55Kg/80Kg |
Details
2 High-precision Heads
±180° rotation
Satisfy the need of wide range components
Flexible PCB positioning
Put the component anywhere
handl well different shape of PCB
Patented automatic Peel-box
Patented electromagnetic actuators
saves you more time and effort
Integrated Controller
More stable performance and easier to do maintenance.
Quality control
We have QC person stay on the production lines do to the inspection.
All products must have been inspected before delivery.
we do inline inspection and final inspection.
1. All raw material checked once it arrive our factory.
2. All pieces and logo and all details checked during production.
3. All packing details checked during production.
4. All production quality and packing checked on final inspection after finished.
Provide one-stop SMT assembly production line
Especially a good choice for customers who prefer in prototype project as a startup device. If you need, please feel free to coantact us.
FAQ
Q1: How can I buy machine from you?
A: (1) Consult us on line or by e-mail.
(2) Negotiate and confirm the final price, shipping, payment method and other terms.
(3) Send you the perfroma invoice and confirm your order.
(4) Make the payment according to the method put on proforma nvoice.
(5) We prepare your order in terms of the proforma invoice after confirming your full payment. And 100% quality check before shipping.
(6) Send your order via express or by air or by sea.
Q2: What's the way of shipping?
A: These are all heavy machines;
We suggest you use cargo ship.
But components for mending the machines, air transportation would be fine.
Q3: Can we customize the machine?
A: Of course.
All of our machines can be customized.
About us
Factory
Certification
Exhibition
If you need, please feel free to contact us for more information!
