PCB LED SMT Machine SMD Chip Mouter
Description
NeoDen K1830 is a high-speed chip mounter with high accuracy, which has 8 pick-up heads, it has been designed for ease of use, high-efficiency, cost-effectiveness, and increasing expandability and compatibility. Using new, highly efficient linear servo motors, lightening and stiffening the head unit, and reviewing the placement speed of 16,000 CPH. It is a great choice for PCB LED SMT SMD assembly work.
Features
1. 8 working heads.
2. The machine runs on a Linux operating system.
3. Double mark cameras to reach at extreme end feeders for better calibration.
4. High resolution and speed component camera system.
5. Ethernet communication interface for all internal signal travel.
6. Closed-loop servo control system with feedback.
7. Picking location of pneumatic feeder can be calibrated automatically and promptly.
8. PCB location can be calibrated automatically and promptly.
Specification
| Product name | NeoDen K1830 PCB LED SMT Machine SMD Chip Mouter | Max Placement Speed | 16,000CPH |
| Nozzle Q'ty | 8pcs | Voltage | 220V/50HZ & 110V/60HZ |
| Reel Tape Feeder Q'ty (Max | 66 (Electric / Pneumatic) | PCB Transfer Direction | Left→Right |
| Max PCB size | 540*300mm (In Single Step) | Net Weight | 280Kgs |
| Placement accuracy | 0.01mm | Gross Weight | 360Kgs |
About Us
factory
certification
exhibition
Zhejiang NeoDen Technology Co., LTD., founded in 2010, is a professional manufacturer specialized in SMT Pick and Place Machine, Reflow Oven, Stencil Printing Machine, SMT Production Line and other SMT Products. We have our own R & D team and own factory, taking advantage of our own rich experienced R&D, well trained production, NeoDen wins great reputation from the world wide customers.
