Introduction
NeoDen4 is a High Precision SMT Pick and Place Machine, PCB flexibility and production flexibility. It is equipped with dual CCD cameras, auto rails, auto electronic feeders and 4 placement heads, which could support to mount 0201, BGA, QFN.
NeoDen4 is a good choice to satisfy all demands of PCB assembly equipment with high precision, stable performance and low cost.
Placement Video for high precision smt pick and place machine
Highlights
1. Vision system
An up-looking camera and a down-looking camera identifies and calibrates the different components simultaneously, and tremendously improves the accuracy of placement from 0201 to BGA.
2. Four precision heads
4 high-precision placement heads with ±180° rotation that adopts suspended, fully symmetric and high degree of coupling way, to ensure it can mount components with higher space, more gentle and more accurate of being a PCB assembly equipment.
3. Auto Electronic Feeders
Adopts feeding error corrections technique to help smooth the picking and reduce the deviation.
Feature
|
NeoDen 4 |
with Internal Rails |
|
Head with Vision enabled QTY: 4 |
Mounting Speed: With vision: 5000/Without vision: 10000 |
|
Mounting Area |
Without waffle Tray: 310*1500MM |
|
With 1 waffle Tray: 140*1500MM |
|
|
Suitable Components |
Smallest Component size: 0201 / Largest Component size: TQFP240 |
|
Automatic Feeding |
None/Yes |
|
Feeder capacity |
Tape Reel Feeders: 48 (all 8 mm) |
|
Vibrations Feeders: 5 |
|
|
IC tray capacity: 5 |
Component Max Height: 5MM |
|
Resolution |
X/Y axis: 0.01MM Z axis: 0.1MM |
|
Rotation: +/-180°(360°) |
Vacuum Pressure: 0.9kp |
|
Power Supply: 110V/220V |
Power: 180W |
|
Vision Camera |
CCD High Accuracy |
|
Vision Qty: Dual Vision |
Recognition Capability: Max 30*30mm |
|
Packing size: 94*74*60CM |
External Dimensions Machine: 87*68*48CM |
|
Net Weight: 60KGS |
Gross weight: 80Kg |
Why Choose NeoDen?
Quality
NeoDen has owned more than 50 patents and TUV NORD CE certificate.
From 1st generation to 4th generation, NeoDen pick and place machine have gained applause from thousands of electronics hobbyists, start-up owners, lab researchers for its high accuracy, stable performance and affordable price.
Easy to Operate
With build-in PC, you only need a monitor & keyboard to control the machine.
Once you generate the coordinate file from PCB design software (AD, Eagle, KiCad, Upverter, etc), it would only take 5-15 mins to program.
Efficient After Sales Service
NeoDen has 11 after-sales engineers, act as the strong power back supporters to help users in maintenance and technical support. We shall help to provide a solution within 1-2 hours if any questions arise. The after-sales team works both workday and holidays.
About Us
factory
certification
exhibition
