Tabletop SMT Pick And Place Machine
NeoDen YY1 Pick and Place Machine
Feature
1. Patent-protected & new needle module is specially designed based on the linear rail with high reliability and durability
2. Independent high-definition & high-speed dual vision recognition systems, as well as dual cameras for real-time display the working status.
3. NeoDne YY1 supports bulk component feeder, strip feeder and IC tray feeder.
4. Small size with powerful magazines and newly designed tape feeders to support large tape reels configuration flexibly, easy to install and replace tape reels conveniently, to ensure the most excellence solution among all of the entry level machines with lower budget but higher stability.
5. Works in a near-perfect silent mode, making it a green and pollution-free pick and place machine.
Specification
| Product name | NeoDen YY1 Tabletop SMT pick and place machine | Nozzle Change Capacity | 3 Nozzles |
| Machine Style |
Single Gantry With 2 Heads |
Component Range | Smallest Size: 0201 |
|
Placement Rate |
Vision On: 3000CPH |
Largest Size: 18*18mm | |
| Vision Off: 4000CPH | Max Height: 12mm | ||
|
Feeder Capacity |
Tape Feeder: 52 (all 8mm) |
Rotation | ±180° |
|
Stick Feeder: 4 |
External Dimensions | Machine Size: 643(L)x530(W)x601(H)mm | |
|
Flexible Feeder: 28 |
Packing Size: 700(L)x580(W)x585(H) mm(wooden box) | ||
|
Bulk Feeder: 19 |
Detail
Powerful Magazines
Small size with powerful magazines and newly designed tape feeders to support large tape reels configur ation flexibly,
easy to install and replace tape reels conveniently.
Brand new patented peeling gadget
It's simple but functional, it’s easy to install and flexible to remove.
Compared with the peelers of TM240A, it doesn't need to collect wasted film.
Compared with the peelers of 3V, it solve the issue of unstability and offset issue.
User friendly touch screen
It comes with a high-definition capacitive touch screen,
which can be adjusted up and down to meet the needs of different viewing angles and enhance the user experiences.
Vacuum detection and real-time display
Equipped with a vacuum detection function, can set standard vacuum detection values on placement head flexibly, all information can be displayed visually on the placement head.
Dual vision system with built-in IC
Independent high-definition & high-speed dual vision recognition systems, as well as two cameras for real-time display the working status, the speed of processing components' photos becomes more efficient and accurate.
Auto nozzle changer
It has 3 slots for nozzles replacement, which realizes maximum optimum of nozzles and achieve higher continuity of production.
Quality Control
We have QC person stay on the production lines do to the inspection.
All products must have been inspected before delivery.
We do inline inspection and final inspection.
1. All raw material checked once it arrive our factory.
2. All pieces and logo and all details checked during production.
3. All packing details checked during production.
4. All production quality and packing checked on final inspection after finished.
If you need, please feel free to contact us for more information.
FAQ
Q1. Can we be your agent?
A. Yes, welcome to cooperation with this.
We have big promotion in the market now.
For the details please contact with our overseas manager.
Q2. Can l visit your factory?
A. By all means, we warmly welcome your arrival.
Before you take off from your country, please let us know.
We will show you the way and arrange time to pick you up if possible.
Q3. Can I request to change the form of packaging and transportation?
A. Yes, we can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.
Q4. What's your products?
A. SMT machine, AOI, reflow oven, PCB loader, stencil printer.
Q5. Do you have a export licence?
A. Yes.
Factory
Quick facts about NeoDen
Established in 2010, 200+ employees, 8000+ Sq.m. factory.
NeoDen products: Smart series PNP machine, NeoDen K1830, NeoDen4, NeoDen3V, NeoDen7, NeoDen6, TM220A, TM240A, TM245P, reflow oven IN6, IN12, Solder paste printer FP2636, PM3040.
Successful 10000+ customers across the globe.
30+ Global Agents covered in Asia, Europe, America, Oceania and Africa.
R&D Center: 3 R&D departments with 25+ professional R&D engineers.
Listed with CE and got 50+ patents.
30+ quality control and technical support engineers, 15+ senior international sales, timely customer responding within 8 hours, professional solutions providing within 24 hours.
Certification
Exhibition
Other Production Line for Your Choice
If you need, please don't be hesitate to send your inquiry.
