NeoDen K1830 SMT Machine for PCB Assembly
Feature
1. Machine runs on highly stable and secure Linux operating system.
2. Double mark cameras to reach at extreme end feeders for better calibration.
3. High resolution and high speed component camera system improves the overall speed of the machine.
4. Picking location of pneumatic feeder can be calibrated automatically and promptly,to ensure easy operation and high efficiency.
5. PCB location can be calibrated automatically and promptly,based on the correct and specific placement request.
Specification
| Product name | NeoDen K1830 SMT machine for PCB assembly | Max Placement Speed | 16,000CPH |
| Nozzle Q'ty | 8pcs | Voltage | 220V/50HZ & 110V/60HZ |
| Reel Tape Feeder Q'ty (Max | 66 (Electric / Pneumatic) | PCB Transfer Direction | Left→Right |
| Max PCB size | 540*300mm (In Single Step) | Net Weight | 280Kgs |
| Placement accuracy | 0.01mm | Gross Weight | 360Kgs |
Detail
High speed Nozzle
8 Synchronized Nozzles
Ensure a repeatable placement accuracy
Pneumatic Feeder
66 Reel Tape Feeder
Easy operation and high efficiency
Vision system
Double mark cameras
Front and rear high definition flight camera
Drive Motor
Panasonic Servo Motor A6
Make the machine to function more accurate
Computer
Display size: 12 inch
Makes the machine more convenient to use
Warning light
Triple color of light
Beautiful and elegant indicator design
Quality control
We have QC person stay on the production lines do to the inspection.
All products must have been inspected before delivery.
We do inline inspection and final inspection.
1. All raw material checked once it arrive our factory.
2. All pieces and logo and all details checked during production.
3. All packing details checked during production.
4. All production quality and packing checked on final inspection after finished.
If you need, please feel free to contact us for more information.
FAQ
Q1. How can I place an order?
A: You can contact any of our sales person for an order.
Please provide the details of your requirements as clear as possible.
So we can send you the offer at the first time.
For designing or further discussion, it is better to contact us with Skype, TradeManger or QQ or WhatsApp or other instant ways, in case of any delays.
Q2. Can we visit your factory before place the order?
A: Yes, very welcome that must be nice to set up good relationship for business.
Q3. Can I request to change the form of packaging and transportation?
A: Yes, we can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.
About us
Factory
Quick facts about NeoDen
Established in 2010, 200+ employees, 8000+ Sq.m. factory.
NeoDen products: Smart series PNP machine, NeoDen K1830, NeoDen4, NeoDen3V, NeoDen7, NeoDen6, TM220A, TM240A, TM245P, reflow oven IN6, IN12, Solder paste printer FP2636, PM3040.
Successful 10000+ customers across the globe.
30+ Global Agents covered in Asia, Europe, America, Oceania and Africa.
R&D Center: 3 R&D departments with 25+ professional R&D engineers.
Listed with CE and got 50+ patents.
30+ quality control and technical support engineers, 15+ senior international sales, timely customer responding within 8 hours, professional solutions providing within 24 hours.
