SMT Surface Mount Equipment
surface mount equipment
Feature
The self-developed flying camera recognition system uses imported CMOS sensor, 5 million-level industrial high- definition lens and 289 LED s ring shadowless light source s,to ensure the stable and durable effects.
The screw used in the machine is a C5 precision ground screw, with an accuracy of 0.018mm within the length 300mm. It is matched with Taiwan PVP and Japan Miki's couplings, coupled with precision assembly, less wear and aging, stable and durable precision.
Equips with the magnetic scale technology what used commonly in the well-known brands , realizing true closed-loop control, long-term assurance of stable placement accuracy as initial & new conditions, easy to calibrate accuracy without suppliers' engineers.
Specification
| Product Name | SMT Surface Mount Equipment | Number of Heads | 6 |
| Number of Tape reel Feeders | 53(Yamaha Electric/Pneumatic) | Number of IC Tray | 20 |
| Placement Area | 460mm*300mm | MAX Mounting Height | 16mm |
| PCB Fiducial Recognition | High Precision Mark Camera | Component Recognition | High Resolution Flying Vision Camera System |
| XY Motion feedback control | Closed loop control system | XY Drive motor | Panasonic A6 400W |
| Repeat Position Accuracy | ±0.01mm | Maximum Mounting Speed | 14,000CPH |
| Average Mounting Speed | 9,000CPH | X-axis-Drive Type | WON Linear Guide / TBI Grinding screw C5 - 1632 |
| Y-axis-Drive Type | WON Linear Guide / TBI Grinding screw C5 - 1632 | Compressed Air | ＞0.6Mpa |
| Input Power | 220V/50HZ(110V/60HZ Alternative) | Machine Weight | 500KG |
| Machine Dimension | L1220mm*W800mm*H1350mm |
Detail
6 Placement Heads
Independent control
Each head can be up and down separately, easy to pick up
Meet the requirements of flexible SMT processing.
Tape Reel Feeders
Supports both electric feeder and pneumatic feeder at max 53 slots tape reel feeders with machine width 800mm only, to ensure the high efficiency with flexible & worthiest space.
Self-developed Flying Camera
Recognition system uses imported CMOS sensor, 5 million-level industrial high- definition lens and 289 LED s ring shadowless light sources, to ensure the stable and durable effects.
C5 precision ground screw
with an accuracy of 0.018mm within the length 300mm. It is matched with Taiwan PVP and Japan Miki's couplings, coupled with precision assembly, less wear and aging, stable and durable precision.
Servo Motor
Equips Panosonic 400W servo motor,
to ensure better torque and acceleration for achiving stable and durable placement.
Patent Sensors
If the feeder is not installed in the correct position, the placement head will be locked, to avoid head bumps and abnormalities by misoperation.
Our Service
We are in a good position not only to supply you high quality pnp machine, but also the excellent after sales service.
Well-trained engineers will offer you any technical support.
10 engineers powerful after-sales service team can respond customers queries and enquiries within 8 hours.
Professional solutions can be offered within 24 hours both workday and holidays.
If you need, please feel free to contact us for more information.
FAQ
Q1: What's your MOQ?
A: Most of our products MOQ is 1 set.
Q2: What's is your shipping service?
A: We can provide services for vessel booking, goods consolidation, customs declaration, shipping documents preparation and delivery bulk at the shipping port.
Q3: What's your tem of the delivery?
A: Our ordinary delivery term is FOB Shanghai.
We also accept EXW, CFR, CIF, DDP, DDU etc.
We'll offer you the shipping charges and you can choose the one which is the most convenient and effective for you.
