PCB Components Assembly Machine
NeoDen10 has been discontinued. Looking for an upgrade?
Discover the NeoDen N10P - a more powerful and superior alternative that's the ideal choice for your needs.
NeoDen10 PCB Components Assembly Machine video
Feature
1. Marbel body, weight 1100KG, stand solid without shaking.
2. The magnetic linear encoder system real-time monitor the machine's accuracy and enables machine to correct error parameter automatically.
3. 8 independent heads with fully closed-loop control system support all 8mm feeder pick up simultaneously, speed up to 13,000 CPH.
4. Support up to 4 pallet tray of chips (optional configuration), larger range and more option.
Specification
| Product name | NeoDen10 PCB Components Assembly Machine | Placement accuracy | 0.01mm |
| Nozzle Q'ty | 8pcs | Max Placement Speed | 18,000CPH |
| Reel Tape Feeder Q'ty (Max | 66 (Electric / Pneumatic) | Average Mounting Speed | 13,000CPH |
| Max PCB size | 500*300mm (1500mm optinal) | Voltage | 220V/50HZ & 110V/60HZ |
| Operation System | Patented SMT Mouting Operation System V1.0 | PCB Transfer Direction | Left→Right |
| Net Weight | 1100Kgs | Machine Dimensions | L1300mm*W1100mm*H1375mm |
Detail
High speed Nozzle
8 Synchronized Nozzles
Ensure a repeatable placement accuracy
Pneumatic Feeder
66 Reel Tape Feeder
Easy operation and high efficiency
Vision system
Double mark cameras
Front and rear high definition flight camera
Drive Motor
Panasonic Servo Motor A6
Make the machine to function more accurate
Computer
Display size: 12 inch
Makes the machine more convenient to use
Warning light
Triple color of light
Beautiful and elegant indicator design
Packaging & Shipping
Packaging
One piece in one wooden case
Suitable quantity to an export wooden case
Other packing accessories in regular
Customer required packing is available
Shipping
by air, sea, or express
Delivery time
about 15~30 days after order details and production confirmed.
If you need, please feel free to contact us for more information.
About us
Factory
Certification
Exhibition
FAQ
Q1. How can I place an order?
A: You can contact any of our sales person for an order.
Please provide the details of your requirements as clear as possible.
So we can send you the offer at the first time.
For designing or further discussion, it is better to contact us with Skype, TradeManger or QQ or WhatsApp or other instant ways, in case of any delays.
Q2. Is there the products tested before shipping?
A: Yes, of course.
All of our conveyor belt we all will has been 100% QC before shipping.
We test every batch every day.
Q3. Can I request to change the form of packaging and transportation?
A: Yes, we can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.
If you need, please don't be hesitate to send your inquiry.
