SMT Production Line NeoDen YY1
sMT production line NeoDen YY1
Introduction
1. Auto nozzle changer
It has 3 slots for nozzles replacement, which realizes maximum optimum of nozzles and achieve higher continuity of production.
2. Vacuum detection and real-time display
Equipped with a vacuum detection function, can set standard vacuum detection values on placement head flexibly, all information can be displayed visually on the placement head.
3. Flexible IC tray, vibration feeder and short cut tapes
The flexible feeders are all magnetic and can be moved on the platform as you want.
To provide customers the most excellence solution among all of the entry level machines with a lower budget but higher flexibiliyu.
The newly-designed stick feeder with its compact shape, is perfectly compatible with the tape feeder system.
It won't occupy any space of tape&reel feeder.
Specifications
| Product name | NeoDen YY1 pick and place machine | Nozzle Change Capacity | 3 Nozzles |
| Machine Style |
Single Gantry With 2 Heads |
Component Range | Smallest Size: 0201 |
|
Placement Rate |
Vision On: 3000CPH |
Largest Size: 18*18mm | |
| Vision Off: 4000CPH | Max Height: 12mm | ||
|
Feeder Capacity |
Tape Feeder: 52 (all 8mm) |
Rotation | ±180° |
|
Stick Feeder: 4 |
External Dimensions | Machine Size: 643(L)x530(W)x601(H)mm | |
|
Flexible Feeder: 28 |
Packing Size: 700(L)x580(W)x585(H) mm (wooden box) | ||
|
Bulk Feeder: 19 |
Details
Shipping Details
Packing: Wooden case
Delivery: 5-7 working days after 100% payment.
DHL /FedEx/TNT (door to door service) are standard shipping methods.
sMT production line
Warranty
The guarantee period is 2 years from the time of purchase and lifelong service support as well as a long-term factory price supply.
NeoDen will provide online Q/A and troubleshooting support and technical advice service.
About Us
factory
1. NeoDen is a professional designer and manufacturer of desktop pick and place machine with 30 patents and CE certificate.
2. The after-sale service team consists of 14 professional engineers, which helps to respond to customers queries and enquiries within 8 hours, provide professional solutions within 24 hours both workday and holidays.
3. NeoDen uses standard export packaging, which is the recycled wooden crate, not only safer in transportation but also better in environmental protection.
certification
exhibition
