Manual Pick and Place Machine for SMD Chip
NeoDen 3V has been discontinued. Looking for an upgrade?
Discover the NeoDen YY1, a more powerful and cost-effective alternative built to exceed your needs.
Manual Pick And Place Machine For SMD Chip
Pick and place machine - NeoDen3V
NeoDen3V Manual Pick And Place Machine is an upgraded version of TM245P series-main upgrade part-Cameras/vision system.
It features dual head, 25 feeder slots ,vision system, and flexible positioning system, which is suitable for prototyping, small batch production with stable performance and affordable price.
Specification
|
Produt name |
Manual pick and place machine for SMD chip |
|
Number of heads |
2 |
|
Alignment |
Vision |
|
Rotation |
±180° |
|
Placement Rate |
5000CPH (without vision); 3500CPH (with vision) |
|
Feeder Capacity |
Tape feeder: 24 (all 8mm) |
| Vibration feeder: 0~5 | |
|
Tray feeder: 5~10 (Customization supported) |
|
|
Board Dimension |
Maximum: 320*420mm |
|
Component Range |
Smallest components: 0402 |
| Largest components: TQFP144 | |
| Max height: 5mm | |
|
Numbers Of Pumps |
3 |
|
Placement Accuracy |
±0.02mm |
|
Operate System |
Windows XP-NOVA |
|
Power |
160~200W |
|
Electricity Supply |
110V/220V |
|
Machine Size |
820(L)*650(W)*410(H)mm |
|
Packing Size |
1001(L)*961(W)*568(H)mm |
| N.W./G.W. |
55Kg/80Kg |
Manual Pick And Place Machine For SMD Chip placement video
Features
Full Vision 2 Head System
2 high-precision placement heads with ±180° rotation could satisfy the need of wide range components.
Patented Automatic Peel-box
Patented electromagnetic actuators, you don't need to get rid of the wasted nylon film manually, which saves you more time and effort.
Flexible PCB positioning
By using PCB support bars and pins, wherever you want to put the PCB and whatever the shape of your PCB is, all can be handled well.
If you prefer to any protoype placement work, a NeoDen3V will be a good choice for Manual Pick And Place Machine For SMD Chip with a low budget.
