SMT Desktop Pick And Place Machine
SMT desktop pick and place machine
Feature
1. Dual vision system with built-in IC
Independent high-definition & high-speed dual vision recognition systems, as well as two cameras for real-time display the working status., the speed of processing components' photos becomes more efficient and accurate.
2. Auto nozzle changer
It has 3 slots for nozzles replacement, which realizes maximum optimum of nozzles and achieve higher continuity of production.
3. User friendly touch screen
It comes with a high-definition capacitive touch screen, which can be adjusted up and down to meet the needs of different viewing angles and enhance the user experiences.
4. Easy to do maintenance
The whole machine is highly integrated one-board design, easy maintenance and debugging.
Few boards and pumps on the side of machine, very clear and simple cables.
The side acrylic covers are fixed on the machine with magnetic, which can be easily removed.
There are 4 flexible screws can be loosened to lower the height of machine's frame for shipping.
5. Brand new software
Newly designed software system & UI for visual programming and placement, which allows fast programming on the machine, friendly interface & easy operation.
Specification
| Product name | NeoDen YY1 SMT Desktop pick and place machine | Nozzle Change Capacity | 3 Nozzles |
| Machine Style |
Single Gantry With 2 Heads |
Component Range | Smallest Size: 0201 |
|
Placement Rate |
Vision On: 3000CPH |
Largest Size: 18*18mm | |
| Vision Off: 4000CPH | Max Height: 12mm | ||
|
Feeder Capacity |
Tape Feeder: 52 (all 8mm) |
Rotation | ±180° |
|
Stick Feeder: 4 |
External Dimensions | Machine Size: 643(L)x530(W)x601(H)mm | |
|
Flexible Feeder: 28 |
Packing Size: 700(L)x580(W)x585(H) mm(wooden box) | ||
|
Bulk Feeder: 19 |
Detail
Powerful Magazines
Brand new patented peeling gadget
User friendly touch screen
Vacuum detection and real-time display
Dual vision system with built-in IC
Auto nozzle changer
If you need, please feel free to contact us for more information.
FAQ
Q1. Is there the products tested before shipping?
A. Yes, of course.
All of our conveyor belt we all will has been 100% QC before shipping.
We test every batch every day.
Q2. Can I request to change the form of packaging and transportation?
A. Yes, we can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.
Q3. What is your advantage compared with your competitors?
A. (1). Qualified Manufacturer
(2). Reliable Quality Control
(3). Competitive Price
(4). High Efficiency working (24*7hours)
(5). One-Stop Service
Factory
Company Profile
We are in a good position not only to supply you high quality pnp machine, but also the excellent after sales service.
Well-trained engineers will offer you any technical support.
10 engineers powerful after-sales service team can respond customers queries and enquiries within 8 hours.
Professional solutions can be offered within 24 hours both workday and holidays.
Certification
Exhibition
Other Production Line for Your Choice
If you need, please don't be hesitate to send your inquiry.
