SMD Machine

NeoDen independent research and development on-line dual rails:

The rail system allows automatic feeding of  PCBs, automatic alignment of the board with the camera, and automatic ejection from the front of the  machine or the rear.

Rear-ejection is useful when the machine is connected to an optional conveyor  that can deliver the finished board directly to the reflow oven or to another NeoDen4.

Four high precision nozzles

1. Any size nozzle can be installed in any of the four  locations in the head, so a single machine can handle all of the necessary components without the  need for nozzle changes.

2. The spring-loaded nozzles simply snap in and pull out of the head. Any  nozzle can be installed in any of the four locations on the head.

Vision system

Installed with high speed industry CCD cameras, and work with our patented image distortion processing algorithms, enable cameras can recognize and align different components of four nozzles. With the help of upper-camera and down looking camera, they will display the picking process with high definition image.

48 8mm tape-and-reel feeders

The electric feeders are inexpensive but sophisticated microprocessor controlled units paired will tape peelers.  In addition, the vibration feeder (included) can handle up to  5 separate tubes.

The amount of space available for tray-fed components and short tapes depends on  the available real estate on the table.  Any area of the table may be used for components awaiting  placement, or for the board under manufacture.
