SMD Machine Automatic
NeoDen SMD Machine Automatic Video
NeoDen SMD Machine Automatic
Feature
Installed with high speed industry CCD cameras,and work with our patented image distortion processing algorithms, enable cameras can recognize and align different components of four nozzles.
with the help of upper-camera and down looking camera, they will display the picking process with high definition image.
Multiply efficiency while ensure accuracy.
And by combined their functions of above two parts precisely, our Neoden4 can easily mount high precision components in the market such as 0201, SOT-23, QFN, BGA which are difficult for most pnp machines.
Meanwhile, because of our unique mechanical structure, Neoden 4 can easily handle odd-form components.
Specification
| Product name | NeoDen SMD Machine Automatic | Feeders | 48pcs |
| Machine Style | Single Gantry with 4 Heads |
Average working power |
220V/160W |
| Placement Rate | 4000CPH | Component Range | Smallest Size: 0201 |
| External Dimension | L 680*W 870*H 460mm | Biggest Size: TQFP240 | |
| Max applicable PCB | 310mm*1200mm | Max Height: 5mm |
Details
Four Nozzles
Any size nozzle can be installed
Designed in a suspended, fully symmetric
Mount at the same time with 360 degrees
Auto Rails
A. Support connect to conventional conveyor directly.
B. Set the feeding position at anywhere.
C. Mount overlong boards easily.
Vision System
(up-looking and down-looking camera)
Equip with high speed industry CCD cameras
Highly improved accuracy of placement from 0201 to BGA
Electronic Feeders
8mm tape-and-reel feeders
Adopts feeding error corrections technique
handle up to 5 separate tubes
Package
Our Service
1. More Professional service in PNP machine field
2. Better manufacture ability
3. Various payment term to choose: T/T, Western Union, L/C, Paypal
4. High quality/Safe material/Competitive price
5. Small order available
6. Quickly response
7. More safe and fast transport
Provide one-stop SMT assembly production line
FAQ
Q1: How long is your delivery time?
A: The general delivery time is 15-30 days after receiving your order confirmation.
Anther, if we have the goods in stock, it will only take 1-2 days.
Q2: What's your tem of the delivery?
A: Our ordinary delivery term is FOB Shanghai.
We also accept EXW, CFR, CIF, DDP, DDU etc.
We'll offer you the shipping charges and you can choose the one which is the most convenient and effective for you.
Q3: What about the lead time for mass production?
A: Honestly, it depends on the order quantity and the season you place the order.
Alway 15-30 days based on general order.
About us
Factory
30+ quality control and technical support engineers, 15+ senior international sales, timely customer responding within 8 hours, professional solutions providing within 24 hours.
Established in 2010 with 100+ employees & 8000+ Sq.m. factory of independent property rights, to ensure the standard management and achieve the most economic effects as well as saving the cost.
Owned the own machining center, skilled assembler, tester and QC engineers, to ensure the strong abilities for NeoDen machines manufacturing,quality and delivery.
40+ global partners covered in Asia, Europe, America, Oceania and Africa, to successfully serve 10000+ users in all of the world, to ensure the better and faster local service and prompt response.
The unique one among all of the Chinese manufacturers who registered and approved CE by TUV NORD.
NeoDen supplies life-long technical support and service for all of the NeoDen machines, moreover, regular software updates based on the using experiences and actual daily request from the endusers.
Certification
Exhibition
Other Production Line for Your Choice
If you need, please feel free to contact us!
