NeoDen YY1 SMT Machine
Feature
1. NeoDen YY1 SMT machine independent high-definition & high-speed dual vision recognition systems,as well as dual cameras for real-time display the working status.
2. Linear rail design for X, Y axis to ensure accuracy and stability, and reduce noise at the same time.
3. Small size with powerful magazines and newly designed tape feeders to support large tape reels configuration flexibly, easy to install and replace tape reels conveniently, to ensure the most excellence solution among all of the entry level machines with lower budget but higher stability.
4. The newly-designed stick feeder with its compact shape, is perfectly compatible with the tape feeder system.
Specification
| Product name | NeoDen YY1 SMT machine | Feeder Capacity | Tape Feeder: 52 (all 8mm) |
| Machine Style | Single Gantry With 2 Heads | Stick Feeder: 4 | |
Placement Rate | Vision On: 3000CPH | Flexible Feeder: 28 | |
| Vision Off: 4000CPH | Bulk Feeder: 19 | ||
| Nozzle Change Capacity | 3 Nozzles | Rotation | ±180° |
| Component Range | Smallest Size: 0201 | External Dimensions | Machine Size: 643(L)x554(W)x601(H)mm |
Largest Size: 18*18mm | Packing Size: 700(L)x610(W)x595(H) mm(wooden box) | ||
| Max Height: 12mm |
Detail
Powerful Magazines
Small size with powerful magazines and newly designed tape feeders to support large tape reels configur ation flexibly,
easy to install and replace tape reels conveniently.
Brand new patented peeling gadget
It's simple but functional, it’s easy to install and flexible to remove.
Compared with the peelers of TM240A, it doesn't need to collect wasted film.
Compared with the peelers of 3V, it solve the issue of unstability and offset issue.
User friendly touch screen
It comes with a high-definition capacitive touch screen,
which can be adjusted up and down to meet the needs of different viewing angles and enhance the user experiences.
Vacuum detection and real-time display
Equipped with a vacuum detection function, can set standard vacuum detection values on placement head flexibly, all information can be displayed visually on the placement head.
Dual vision system with built-in IC
Independent high-definition & high-speed dual vision recognition systems, as well as two cameras for real-time display the working status, the speed of processing components' photos becomes more efficient and accurate.
Auto nozzle changer
It has 3 slots for nozzles replacement, which realizes maximum optimum of nozzles and achieve higher continuity of production.
Packaging & Shipping
Packaging:
One piece in one wooden case
Suitable quantity to an export wooden case
other packing accessories in regular
Customer required packing is available
Shipping: by air, sea, or express
Delivery time: about 15~30 days after order details and production confirmed.
If you need, please feel free to contact us for more information.
Q1: Are you trading company or manufacturer?
A: We are professional manufacturer specialized in SMT production line.
And we trade our products with our clients directly.
Q2: Which payment form you can accept?
A: T/T, Western Union, PayPal etc.
We accept any convenient and swift payment term.
Q3: What's is your shipping service?
A: We can provide services for vessel booking, goods consolidation, customs declaration, shipping documents preparation and delivery bulk at the shipping port.
About us
Zhejiang NeoDen Technology Co., Ltd. has been manufacturing and exporting various small pick and place machines since 2010. Taking advantage of our own rich experienced R&D, well trained production, NeoDen wins great reputation from the world wide customers.
With global presence in over 130 countries, the excellent performance, high accuracy and reliability of NeoDen PNP machines make them perfect for R&D, professional prototyping and small to medium batch production. We provide professional solution of one stop SMT equipment.
If you need, please don't be hesitate to send your inquiry.
